One SSRF Bug, Zero Passwords: How a Web App Hands Over Your AWS Keys (and the 1-Line Fix)

Steal your own EC2 role credentials through the metadata service, then flip one setting and watch the attack die. A hands-on IMDSv1 vs IMDSv2 lab with the full SSRF attack chain, org-wide enforcement, GuardDuty detection, and a checklist.

Shivaji Rathod

Cybersecurity Enthusiast | Aspiring Cloud Security Engineer

Published Oct 7, 2026

Last modified Oct 7, 2026

TL;DR: Every EC2 instance can ask a "magic URL" for its own IAM credentials. If a web app has an SSRF bug and the instance still allows IMDSv1, an attacker can make the app fetch that URL and hand over working AWS keys. IMDSv2 breaks that chain. In this lab you'll steal your own keys, flip one setting, and watch the same attack die.

Start here: what's wrong with this URL?

A site has a feature: "Paste an image URL and we'll fetch a preview."

1
https://shop.example.com/preview?url=https://cdn.example.com/cat.png

An attacker changes it to:

1
https://shop.example.com/preview?url=http://169.254.169.254/latest/meta-data/iam/security-credentials/

What comes back?

A) Nothing, that IP isn't routable B) An error page C) The name of the IAM role attached to the server, and one more request away, its access keys D) A 403 from AWS

If you said C, you've just understood one of the most famous cloud attack chains. If you said A, keep reading, because 169.254.169.254 only works from inside the instance, and the vulnerable app is inside the instance.

What you'll get

✅ What the metadata service (IMDS) is and why it exists
✅ The full SSRF to stolen-keys attack chain, step by step
✅ A 15-minute lab: steal your own test keys, then block the attack
✅ Why IMDSv2 stops it (and what it does not stop)
✅ How to enforce it across an account, and detect abuse
✅ A checklist and a cheat sheet

🪪 The mental model: a name tag the server reads off itself

Your EC2 instance needs AWS credentials to call S3, DynamoDB, and so on. AWS doesn't want you to hardcode keys, so it gives the instance an IAM role and a way to ask for temporary credentials.

That "way to ask" is the Instance Metadata Service (IMDS), a local-only HTTP endpoint at 169.254.169.254. Anything running on the box can call it with no password. That's convenient, and that's the problem: "anything running on the box" includes a vulnerable web app that an attacker can steer.

	IMDSv1	IMDSv2
How you call it	Plain GET	PUT to get a session token, then GET with a token header
Needs custom headers?	No	Yes
Needs a PUT request?	No	Yes
Typical SSRF can abuse it?	Yes	Generally no

🧨 The attack chain

1
2
3
4
5
6
7
8
9
10
11
12
13
14
 Attacker                Web app on EC2              IMDS (169.254.169.254)
    |                          |                              |
    | 1. /preview?url=http://169.254.169.254/...              |
    |------------------------->|                              |
    |                          | 2. server fetches that URL   |
    |                          |----------------------------->|
    |                          |                              |
    |                          | 3. role name + temp keys     |
    |                          |<-----------------------------|
    | 4. app returns the keys inside the "preview"            |
    |<-------------------------|                              |
    |                                                         |
    | 5. attacker uses the keys from their own laptop         |
    |    aws sts get-caller-identity  ->  "I am your server"  |

The attacker never logged in to anything. The server made the request on their behalf (that's what SSRF means: Server-Side Request Forgery), and the server was trusted by AWS.

The blast radius is whatever the instance's role allows. An over-permissive role plus IMDSv1 is how a single web bug becomes a data breach. This pattern was at the center of the widely discussed 2019 Capital One incident, which is why it's still taught everywhere.

🧪 Lab: steal your own keys, then block the attack

Use a test account. You'll create a small instance, grab its temporary credentials from inside, then enforce IMDSv2. The role has almost no permissions on purpose. It costs a few cents if you terminate the instance when you're done.

Step 1: Create a low-privilege role and instance profile

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
export AWS_DEFAULT_REGION=ap-south-1
ROLE=lab-imds-role

aws iam create-role --role-name $ROLE --assume-role-policy-document '{
  "Version":"2012-10-17",
  "Statement":[{"Effect":"Allow","Principal":{"Service":"ec2.amazonaws.com"},"Action":"sts:AssumeRole"}]
}'

# Lets us connect with Session Manager (no SSH port, no key pair)
aws iam attach-role-policy --role-name $ROLE \
  --policy-arn arn:aws:iam::aws:policy/AmazonSSMManagedInstanceCore

aws iam create-instance-profile --instance-profile-name $ROLE
aws iam add-role-to-instance-profile --instance-profile-name $ROLE --role-name $ROLE
sleep 15   # let IAM propagate

Step 2: Launch an instance with IMDSv1 allowed

Amazon Linux 2023 requires IMDSv2 by default, so we have to deliberately weaken it to recreate the vulnerable setup:

1
2
3
4
5
6
7
8
9
10
11
12
AMI=$(aws ssm get-parameter \
  --name /aws/service/ami-amazon-linux-latest/al2023-ami-kernel-default-x86_64 \
  --query Parameter.Value --output text)

IID=$(aws ec2 run-instances --image-id $AMI --instance-type t3.micro \
  --iam-instance-profile Name=$ROLE \
  --metadata-options HttpTokens=optional,HttpEndpoint=enabled \
  --tag-specifications 'ResourceType=instance,Tags=[{Key=Name,Value=lab-imds}]' \
  --query 'Instances[0].InstanceId' --output text)

aws ec2 wait instance-status-ok --instance-ids $IID
echo $IID

This uses your default VPC, which gives the instance a public IP so Session Manager can reach it. If you've deleted your default VPC, launch it in a subnet that has internet access or SSM VPC endpoints.

Step 3: Be the attacker (IMDSv1)

Connect to the instance with Session Manager (EC2 console, select the instance, Connect, Session Manager), or from the CLI if you have the plugin: aws ssm start-session --target $IID.

Inside the instance:

1
2
3
4
5
# 1. What role is attached?
curl -s http://169.254.169.254/latest/meta-data/iam/security-credentials/

# 2. Get the credentials for that role
curl -s http://169.254.169.254/latest/meta-data/iam/security-credentials/lab-imds-role

You'll see JSON with AccessKeyId, SecretAccessKey, Token, and Expiration. That's it. No password, no header, one GET. A vulnerable app that fetches arbitrary URLs would hand these over exactly the same way.

Prove the keys work from outside. On your own laptop, in a fresh shell, with the values you just saw (these are temporary and expire, but still don't paste them anywhere public):

1
2
3
4
export AWS_ACCESS_KEY_ID=ASIA...
export AWS_SECRET_ACCESS_KEY=...
export AWS_SESSION_TOKEN=...
aws sts get-caller-identity

The output shows the assumed-role ARN of your instance. You're now "the server," from anywhere on the internet. Then close that shell so the variables don't linger.

Step 4: Flip the switch (defender)

From your normal terminal, not the instance:

1
2
aws ec2 modify-instance-metadata-options --instance-id $IID \
  --http-tokens required --http-endpoint enabled

No reboot. It takes effect within seconds.

Step 5: Repeat the attack

Back in the Session Manager shell:

1
2
3
# The old way: now fails
curl -s -o /dev/null -w "%{http_code}\n" \
  http://169.254.169.254/latest/meta-data/iam/security-credentials/

You get 401. Now the legitimate IMDSv2 way, which your own code and the AWS SDKs do automatically:

1
2
3
4
5
TOKEN=$(curl -s -X PUT "http://169.254.169.254/latest/api/token" \
  -H "X-aws-ec2-metadata-token-ttl-seconds: 60")

curl -s -H "X-aws-ec2-metadata-token: $TOKEN" \
  http://169.254.169.254/latest/meta-data/iam/security-credentials/

It works again, but only because you made a PUT and attached a header. A basic SSRF bug that can only trigger a GET to a URL you control can't do either. Same app, same bug, attack dead.

🧹 Cleanup

1
2
3
4
5
6
7
8
aws ec2 terminate-instances --instance-ids $IID
aws ec2 wait instance-terminated --instance-ids $IID

aws iam remove-role-from-instance-profile --instance-profile-name $ROLE --role-name $ROLE
aws iam delete-instance-profile --instance-profile-name $ROLE
aws iam detach-role-policy --role-name $ROLE \
  --policy-arn arn:aws:iam::aws:policy/AmazonSSMManagedInstanceCore
aws iam delete-role --role-name $ROLE

🔵 Why IMDSv2 works (and its limits)

IMDSv2 raises the bar in three ways:

It needs a PUT. Most SSRF bugs only let the attacker trigger GET requests
It needs a custom header. SSRF through a URL parameter usually can't add one
It rejects requests that look proxied. Requests carrying an X-Forwarded-For header are refused, and the default hop limit of 1 keeps token responses from traveling past the instance

What it does not do:

If an attacker gets remote code execution on the box, they can just do the PUT and read the keys. IMDSv2 mitigates SSRF-style abuse, not a fully compromised host
It doesn't fix an over-permissive role. If the role can read every bucket, a stolen session can too
Containers sometimes need a hop limit of 2 to reach IMDS. Raise it only where you must, and prefer task or pod roles (ECS task roles, IRSA, EKS Pod Identity) over letting containers reach the node's credentials

🛡️ Enforce it everywhere

Fix existing instances: find the weak ones first

1
2
3
aws ec2 describe-instances \
  --query "Reservations[].Instances[]|[?MetadataOptions.HttpTokens=='optional'].[InstanceId,State.Name]" \
  --output table

Run it in every region you use. Before enforcing, check that nothing legacy is still calling IMDSv1. The EC2 CloudWatch metric MetadataNoToken counts calls made without a token. If it's zero for a while, switching is safe.

Fix the default for new launches (per region)

1
aws ec2 modify-instance-metadata-defaults --http-tokens required

Block insecure launches at the organization level

Use a policy that denies ec2:RunInstances unless the request has IMDSv2 required, using the ec2:MetadataHttpTokens condition key, and deny ec2:ModifyInstanceMetadataOptions for everyone except a break-glass role. AWS also offers declarative policies for EC2 metadata defaults at the Organizations level. Check the current docs for the exact syntax before rolling out, since this area changes.

Detect abuse

GuardDuty has findings for stolen instance credentials being used from elsewhere: UnauthorizedAccess:IAMUser/InstanceCredentialExfiltration.OutsideAWS and ...InsideAWS
CloudTrail records ModifyInstanceMetadataOptions. Alert if someone sets HttpTokens back to optional, the same way you alerted on CreateAccessKey earlier in this series
Review role usage: IAM Access Analyzer and last-accessed data help you shrink what a stolen session could ever touch

🔴 Attacker view vs 🔵 Defender view

What the attacker does	What the defender does
Hunts for features that fetch URLs: webhooks, image previews, PDF generators, import-from-URL	Allow-list destinations. Block link-local 169.254.0.0/16 and private ranges in the app
Hits 169.254.169.254 through the vulnerable feature	Require IMDSv2, hop limit 1 unless a container needs more
Reads role name, then credentials	Least-privilege roles so a stolen session is nearly useless
Uses the keys from their own machine	GuardDuty exfiltration findings, CloudTrail anomaly alerts
Enumerates what the role can do	Short role sessions, permission boundaries, SCP guardrails

❌ Mistakes that actually cause incidents

Leaving HttpTokens=optional because "it's an old instance and nothing broke"
A web-facing instance whose role has s3:* or admin
Fetch-a-URL features with no destination allow-list
Raising the hop limit to 2 "to make containers work" on every host
No alert when someone turns IMDSv2 enforcement off
Treating IMDSv2 as a replacement for fixing the SSRF bug itself. It's a safety net, not a fix

✅ Your IMDSv2 checklist

[ ] Audit all regions for instances with HttpTokens=optional
[ ] Check MetadataNoToken before enforcing, so nothing legacy breaks
[ ] Enforce required on existing instances
[ ] Set the account/region default to required
[ ] Launch templates and Auto Scaling groups set HttpTokens=required
[ ] Org-level guardrail denying IMDSv1 launches
[ ] Roles on internet-facing instances reviewed for least privilege
[ ] GuardDuty on, plus an alert on ModifyInstanceMetadataOptions
[ ] Apps that fetch URLs have an allow-list and block link-local ranges

📌 Cheat sheet

I want to...	Run
Find weak instances	describe-instances filtered on HttpTokens=='optional'
Enforce on one instance	aws ec2 modify-instance-metadata-options --instance-id ID --http-tokens required
Default for new launches	aws ec2 modify-instance-metadata-defaults --http-tokens required
Get a v2 token	curl -X PUT .../latest/api/token -H "X-aws-ec2-metadata-token-ttl-seconds: 60"
Call IMDSv2	curl -H "X-aws-ec2-metadata-token: $TOKEN" .../latest/meta-data/...
Spot stolen credentials	GuardDuty InstanceCredentialExfiltration findings

⚠️ Where this falls short

This lab uses a single instance and a near-empty role. Real incidents depend on how much the role can touch, so the role review matters as much as the setting
IMDSv2 is not a fix for code execution, only for the common SSRF path
Always confirm the exact syntax of condition keys and org-level policies in current AWS docs before applying them to production

💬 Your turn

What status code did Step 5 give you before you used the token? Drop it in the comments
How many instances in your account still allow IMDSv1? Run the audit and tell us the number (no account IDs please)
Vote for the next post: 1) IAM role chaining and AssumeRole attacks, 2) investigating an incident with CloudTrail, 3) ECS and EKS: stopping containers from reaching node credentials

Found this useful? Save it for your next AWS interview. 🔖
