Hand a task to a MicroVM from anywhere: one lease, Step Functions, durable functions, or your own controller

A Lambda MicroVM gives you a machine with a lifecycle and an endpoint. An orchestrator wants something narrower: hand that machine one job, go to sleep, and wake up when the job is done or when it has clearly gone wrong. Every workload in part 2  of this series was driven from a terminal or a harness that called the VM's endpoint. The customers I work with at Aivar do not run their pipelines from terminals. They run them from Step Functions, from Lambda, and from whatever queue their platform team standardized on years ago, and the question they ask is how a state machine hands a VM a task and waits.

Three answers arrived at roughly the same time. Step Functions got SDK integrations for Lambda MicroVMs in August 2026, so a state machine can call RunMicrovm as a task state and wait for a task token. Lambda durable functions have callbacks, a single-use id that an outside process completes. Everyone else has a queue. I did not want three integrations, so I built one contract in microvm-ctl  and pointed all three at it; the README puts it in one clause, hand a VM a task from Step Functions, Lambda durable functions, or any orchestrator through a lease the VM completes itself. This is part 4 of Building on AWS Lambda MicroVMs, and every number in it was measured on the live service in us-east-1 on 2026-09-20, on an account with a 1 launch per second quota, against a 2 GB image, and a 512 MiB build of the same agent for the fan-outs.

The idea is small. Whatever token the orchestrator uses to wait (a Step Functions task token, a durable callback id, or a random string you minted) is a lease: single-use, expiring, and only completable by the holder. Instead of polling the VM to RUNNING, minting an endpoint auth token, and POSTing the job in, the orchestrator puts the lease and the task into runHookPayload at launch. Lambda delivers that payload to the /run hook before the endpoint even opens, so the VM is working from its first second and already knows who to tell when it finishes.

The kind picks the completer inside the VM; everything else is the same for every orchestrator. Four concerns differ per kind, and the table from docs/integrations.md  is the whole map:

In exchange the VM makes five promises, all kept by the hook runtime the image builder injects, not by your code. /run answers 200 immediately and the handler runs in a daemon thread, because Lambda holds the launch until /run returns. A second thread heartbeats every heartbeat_s seconds for the kinds that have something to heartbeat against. Failure is typed: a LeaseError raised by the handler becomes {error_type, message, retryable, data}, any other exception becomes Unexpected with a short trace, and a /terminate that lands mid-task sends Terminated with retryable true, so a janitor kill reaches the orchestrator at once rather than at the heartbeat timeout. A success payload over 240 KB is replaced by a truncation marker, under the 256 KB limit on both AWS completion APIs. And when a heartbeat comes back TaskTimedOut or CallbackTimeoutException, the runtime marks the lease lost, the handler's next lease.check() raises, and the VM stops spending on a result nobody is waiting for.

Every completion carries microvm_id, lease_id, elapsed_s, and either result or error. That microvm_id matters more than it looks: a task token is not a VM id, and the orchestrator only learns which VM it leased when the VM says so. Keep that in mind for the timeout branch below.

On the control plane side the whole thing is one call. FleetManager.lease encodes the payload (and refuses anything over the 4,096 character runHookPayload limit rather than letting the service do it), applies a LeasePolicy whose idle policy has auto-resume off (a leased VM that goes idle is finished, not dormant) and whose maximumDurationInSeconds is budget plus slack, and sets the RunMicrovm clientToken to a hash of the lease so a replayed launch returns the same VM.

Every orchestrator in this article leases the same image, examples/handoff-agent . The task is a list of shell steps; each step runs under bash -c, reports a phase, progress, and its output tail, and the first non-zero exit fails the lease with a typed StepFailed. The whole handler is the on_lease decorator plus a loop:

After the loop come two test aids (hang_s sleeps past any budget to drill the heartbeat timeout, fail_after_s raises a retryable Injected error to drill the relaunch path) and the return value, {passed, steps, parallel, microvm_id, heartbeats}, which the runtime delivers as the success payload's result. The snippet above is the sequential path as it shipped in version 1; the image in the repo now also takes "parallel": true and runs the steps on a bounded pool inside the same VM, which the Leases at scale section below measures. Nothing in the handler knows which orchestrator is waiting. The job telemetry calls (phase, progress, log) are always on and served at GET /status and streamed at GET /events whether or not there is a lease, which is what mvm status, mvm watch, and the playground read.

The playground, the browser UI that ships with microvm-ctl, shows the same lease through its Fleet view. Here it is after a kind none lease of four steps that spent 26.7 s in the VM:

The 0 heartbeats is honest and will recur in every run below: kind none has no completer to heartbeat against, and every other task in this article finished inside one 30 s heartbeat interval. The heartbeat thread is exercised in the unit tests and in the hang_s drills, not in these timings.

mvm lease asl generates a JSONata state machine, and examples/stepfunctions-handoff  commits the output as lease.asl.json and inlines it into a CloudFormation template with the stack's ARNs substituted. The state that does the work, trimmed of its Retry block:

Read the Arguments top to bottom and the contract is all there. The task token goes into RunHookPayload, so there is no Lambda function between the state machine and the VM. TimeoutSeconds is the budget, HeartbeatSeconds is three times the VM's 30 s heartbeat, and MaximumDurationInSeconds is budget plus 120 s of slack so the VM dies on its own if the state machine loses track of it. ClientToken is the execution name plus the state name, so a Retry on a throttled RunMicrovm gets the same VM back instead of a second one. The happy path is Lease, Terminate with the microvm_id the VM reported, and Done, whose output is the VM's success payload.

The run. I deployed the stack and ran ./run.sh, which starts an execution with three steps (echo hello, python3 -c "print(2+2)", sleep 5) and polls every 3 s. The first attempt failed immediately with LambdaMicrovms.AccessDeniedException: the state machine role was not authorized to perform lambda:PassNetworkConnector on the INTERNET_EGRESS connector. RunMicrovm passes the ingress and egress connectors even when you name none, an admin user never sees it because the admin policy already carries it, and a role built from the documented actions does not. That finding is now a statement in the orchestrator policy mvm lease policy prints, on arn:aws:lambda::aws:network-connector:aws-network-connector:, and an entry in the troubleshooting guide. With the policy fixed, execution lease-1789932027 showed RUNNING at 12:20:32 and SUCCEEDED at 12:20:36, and its output carried microvm_id microvm-110fe158-bd61-3e32-ab4c-67e9a0637a3e, elapsed_s 5.5, and three passed steps with the outputs hello, 4, and nothing from the sleep.

The failure path has an odd shape, and I exercised it live from a second repo, microvm-handoff-demo , which drives every lease scenario against deployed stacks rather than the unit tests. Two things came out of that.

The typed-failure branch, live: OnLeaseError reads the cause, TerminateFailed ends the VM it names, and GetMicrovm shows it terminated 0.557 s after the failure. From results/stepfunctions/retryable-fail .

The budget timeout, live: each callback times out exactly 60 s after it starts while the VM heartbeats every 10 s in between, the function terminates the VM it holds the id of, and lease_with_relaunch tries once more. From results/durable/hang .

One constraint to design around: Standard workflows only. Express workflows cannot wait for a task token, so a lease from an Express workflow has to nest a Standard one.

The durable version is a library function rather than a document. microvm.integrations.durable.lease_microvm creates the callback with timeout equal to the budget and heartbeat_timeout equal to the policy's, launches through FleetManager.lease inside a step with at-most-once semantics and no SDK retries (so a replay after a crash between the API call and the checkpoint gets the same VM back through the clientToken rather than a second VM), suspends on callback.result(), and terminates the VM in every branch it can see. It returns {status: done | timed_out | failed, result | error, retryable, vm} without raising for any of those, and lease_with_relaunch loops over it while the outcome is retryable, up to max_relaunches more times, each attempt with a fresh callback, a fresh VM, and its own label.

The orchestrator in examples/durable-handoff  reduces to one call around that:

The rule that is easy to get wrong deserves its own paragraph, because the obvious code is the broken code. Do not wrap callback.result() in try/finally. The Python SDK suspends the execution by raising SuspendExecution, a BaseException, out of result(); the invocation ends and Lambda re-invokes when the callback completes. A finally block runs on that raise and would terminate your VM at the moment the function went to sleep. The library catches CallbackTimeoutError and CallbackExternalError by name, terminates in each except branch and once more on the success path, and lets everything else propagate.

I invoked the deployed orchestrator directly with the handoff-agent image and a three-step task ending in a short sleep. The execution history, trimmed to the event and its timestamp:

13.5 s end to end across two short invocations: one to create the callback and launch, one to wake on the callback and terminate. The launch step took 0.83 s, which is RunMicrovm accepting the request, and between the launch step succeeding and CallbackSucceeded the function was suspended and billing nothing while the VM restored, ran the steps, and completed the callback. That example also carries a webhook receiver with deterministic execution names so redelivered pull request events reattach, a five-minute janitor that reaps by age, and a security review agent on the same runtime. The long write-up of the durable half, including the workshop it was shaped after and each failure mode the pieces exist to prevent, is the durable handoff deep dive; I will not repeat it here.

Most pipelines are neither a state machine nor a durable function, and examples/generic-handoff  is for them: a plain Python script that mints a token, calls FleetManager.lease, and waits for the VM's messages over whichever transport you pass as --kind. All three transports end in one SQS queue the controller long-polls, so the loop is identical and only the setup differs.

With sqs the VM sends heartbeat, success, and failure bodies straight to a standard queue; the VM role needs sqs:SendMessage on it. With eventbridge the VM calls PutEvents on a bus with detail types microvm.lease.heartbeat, .success, and .failure, and a rule routes them into the queue; the VM role needs events:PutEvents on the bus. With http the VM POSTs JSON to a URL with Authorization: Bearer <token> using urllib only, so the VM role needs nothing and the completer needs no boto3. The example's collector is a 128 MB Lambda behind a public Function URL that appends each POST and its bearer token to the queue. It does not verify the token; it forwards it for the controller to match. That is a demo of the transport, not an authentication design: put a secret comparison in the handler, or switch the URL to AWS_IAM auth with SigV4 from the VM, before pointing anything untrusted at it.

Every message is matched on the per-run token, so a late heartbeat from an earlier run is discarded rather than misattributed. The budget is enforced client-side and a timed_out run is terminated and reported like any other. There is one honest gap: sqs and eventbridge have no closed-token signal, so a VM whose controller has died keeps sending into the queue until its own maximumDurationInSeconds ends it. That cap is the guarantee, which is why FleetManager.lease always sets it.

I ran the controller twice per kind with a 240 s budget. The p50 total from before RunMicrovm returned to the completion message landing in the queue was 5.29 s for http, 8.78 s for sqs, and 7.10 s for eventbridge, all six runs successful, all with zero heartbeats. The raw records are benchmarks/results/handoff/results-{http,sqs,eventbridge}-*.json in the repository. The spread between kinds in a two-run sample is mostly launch variance on a 1 launch per second account and long-poll granularity, not a property of the transports.

The comparison that matters is all five kinds on the same image, same task, same account, same afternoon. handoff_bench.py in the microvm-ctl repository leases handoff-agent through each orchestrator, reads the VM's /status for the lease-accepted and done timestamps, and reads the orchestrator's own history for when it resumed. Two runs per kind, three for sfn after the retry change described under Leases at scale, two shell steps ending in sleep 3, all eleven runs succeeded. The bench's figure, which also carries the fan-out tables, is under Leases at scale.

Launch to lease is the time from the orchestrator's launch call to the VM logging lease accepted, the snapshot restore plus /run: one to three seconds, consistent with the 3.54 s p50 to serving traffic in part 1  minus the endpoint. Work is what the steps took inside the VM by the VM's own clock, and it is the thinnest column: the bench reads it from /status while the VM is alive, a VM terminated between two polls leaves no reading, and the sfn, sqs, and http figures are single observations. Completion to resume is where the orchestrators actually differ: Step Functions takes a second to notice the completion and run the next state, a durable function 0.3 s, a queue poller 0.2 s; the http 1.7 s is one observation through the collector Lambda. End to end is 5.9 to 10.8 s, and the handoff's own share of it, launch to lease plus completion to resume, is 1.1 to 3.2 s of wall clock and no orchestrator compute worth mentioning.

The cost column is a model on measured seconds, not a bill. A 2 GB, 1 vCPU VM at the published us-east-1 rates is $0.0000276944 per vCPU-second plus 2 x $0.0000036667 per GB-second, $0.0000350278 per second, times the VM seconds per lease. On top of that Step Functions charges four state transitions at $0.000025 each and the durable function three operations at $0.000008 each; the generic kinds add nothing beyond what the queue or bus costs you already. That makes a Step Functions lease a hundredth of a cent more than a queue lease, and none of them reaches a twentieth of a cent. The VM is most of the bill, and it is a seven to ten second VM.

Every lease in this article is one VM, one task, one token, and that stays true when there are eight of them. Parallelism is not a feature of the lease; it is the construct the orchestrator already has, a Step Functions Map, a durable context.map, or a loop in your controller. What the plane adds is the arithmetic that makes a fan-out safe on a given account, before anything launches.

mvm lease plan --image handoff-agent --shards 8 printed concurrency 4 (memory quota 8 GB / 2 GB baseline), 2 waves, launch to all running about 14.5 s, worst case 8160 VM-seconds, $0.2858, no approval needed. The refusal drill asked for 40 shards of the same image: 10 waves, worst case 40800 VM-seconds, $1.43, and lease_many refused with "40 leases exceed the concurrency limit 4; launch in waves", 0 RunMicrovm calls, 0 new VMs. The same plan with --max-vm-seconds 10000 printed "rejected: worst case 40800 VM-seconds exceeds policy max_vm_seconds 10000". Both are the plane saying no in a sentence before the account has spent anything.

mvm lease asl --map wraps the single-lease machine as the item processor of a Map over $states.input.shards, with MaxConcurrency from fanout_limit when you do not pass one; template-map.yaml  in the Step Functions example commits the output. Every shard gets the same Lease, Terminate, OnLeaseError, TerminateFailed, Reap, and TerminateStale states, and the execution output is the array of VM payloads.

The service taught me two things when this machine first deployed, and both live in the emitter now. Inside a JSONata Map item processor there is no $states.context.Map.Item.Index, so indexed_items_expr wraps each shard as {index, task} and the lease id and ClientToken carry that index; a retried shard gets its own VM back, never a neighbour's. And state names must be unique across the whole definition, not per processor, so the shard's terminal state is ShardDone (MAP_DONE_NAME), not a second Done. The Retry block changed too: the generated machine used to wait 10 s before retrying a throttled RunMicrovm, then 20 s, and on a 1 per second quota that dominated one single-lease run, 14.7 s instead of 5.5 s. _retry_throttling now waits 2 s first, 8 attempts, backoff 2, full jitter. With --approval-topic the machine gains a Gate choice that sends executions with more shards than --approve-above-shards through RequestApproval, an sns:publish.waitForTaskToken, so the approval is in the execution history; no answer within an hour ends in Denied. I deployed and validated that template, but every measured fan-out below ran without the gate.

The durable version is microvm.integrations.durable.lease_map(context, fm, image, tasks, policy=..., baseline_mib=...): a plan step first, {status: rejected, reason, plan} without launching when the plan is rejected, an approval callback when the plan is above approval_usd and you pass an approve function, then context.map over the tasks with one lease_with_relaunch per shard at the plan's concurrency, returning the plan and every outcome. The durable example's fanout mode, {"mode": "fanout", "shards": [...]}, is that one call. The launches go through the plane's token bucket, and in the service records they went out 1.2 s apart, 80% of the 1 per second quota.

mvm lease run handoff-agent --shards 4 does the same from a terminal, planning first and exiting 2 on a refusal and 3 when the plan needs approval without --approve. mvm watch --image handoff-agent is one live table for every RUNNING member of an image, with a footer of done over total, running, lost, and the slowest member; the playground's fleet job panel is the same table.

The bench drives the deployed Map and the durable fanout mode with 4 and 8 shards of handoff-agent-small, the same agent at a 512 MiB baseline so all eight fit the quota at once, and takes start and stop from the orchestrator's own record; the three lower tables of the bench's figure are these runs, the in-VM comparison, and the refusal drill.

End to end is the service's clock: describe_execution's start and stop for Step Functions, the durable execution's own timestamps for Lambda. The execution history of the first 8-shard Map run, MaxConcurrency 8, reads ExecutionStarted at 0.0 s, all 8 TaskSubmitted by 0.4 s, the first TaskSucceeded at 8.3 s, the last MapIterationSucceeded at 11.0 s, and ExecutionSucceeded at 11.1 s; the 4-shard run took 13.8 s, and the rerun after the retry change is the table row. Eight VMs cost 77 VM-seconds and $0.00147, of which $0.0008 is 32 Step Functions state transitions, so on a half-GB image the orchestrator is more than half the bill. The durable 8-shard row is slower than its first-pass 16.7 s because the bench saw one of the eight VMs RUNNING only 13.8 s after the service's startedAt for it, and the map waited; the dash in its all-running column is honest, the first VM had been terminated before the last was up. The first and slowest shard done columns are /status observations between polls and are informational: the 4-shard sfn row's first shard done lands 0.2 s after its own end to end. Heartbeats stayed 0 in every shard because every task finished inside 30 s.

The harness lesson, said plainly because it is the mistake you will make too: my first pass reported 43 to 52 s for these fan-outs, because it timed the orchestrator by when its own poll loop saw the terminal state while also polling every member's /status, so the number was the harness, not the service. The fix takes start and stop from describe_execution and get_durable_execution, and VM-seconds from GetMicrovm's startedAt to terminatedAt, and the same runs came back at 11.1 to 16.7 s.

The same lease from both orchestrators, timed only from describe_execution and get_durable_execution: 18 of 18 runs succeeded. The durable function pays for one extra invocation per wave, which is the gap at 4 and 8 shards. From benchmarks/results  in microvm-handoff-demo.

Reach for parallelism inside the VM before you reach for a fan-out. The handoff agent's "parallel": true runs the steps on a thread pool of max_parallel workers, and four sleep 3 steps on one 2 GB VM took 12.5 s of VM time sequentially and 3.6 s in parallel, the steps themselves summing to 12.1 s and 12.3 s; the lease cost $0.00049 against $0.00019. That touches neither quota.

Who controls runaway cost. The account quota is the hard stop and is raised by ticket. The policy is the platform team's ceiling, enforced before launch. The plan is the number the requester reads before spending. Approval above the threshold goes through the orchestrator's own callback and is in its history. After launch, every VM's maximumDurationInSeconds and the reaper bound any mistake. The circuit-breaker  example is the account-wide stop for the day all five agree and the account still holds more memory than it should: a metric on running microVM memory per image, an alarm on the total, a drain function that runs Fleet.drain for every image, and an AWS Budgets action that attaches a Deny on lambda:RunMicrovm to the orchestrator roles when the month's spend crosses the line, so a Lease state fails into Reap and a lease_map fails in its launch step while the VMs already leased finish on their own budgets. I exercised it live on the small image: with the alarm threshold lowered to 1 GiB, four 512 MiB handoff-agent-small VMs ran for about 95 seconds before the metric caught up, the alarm went to ALARM, and the drain function terminated all four in the same minute. The approval gate is deployed and validated as a template, not exercised live.

The contract is documented in docs/integrations.md  in microvm-ctl , installable from PyPI . The four examples, the benchmark results, and the recordings live in awesome-microvm . Part 3  of this series closes with the decision guide for which workloads belong on a MicroVM at all; this part is the answer to what happens once one of them has to be started by something other than a person. The table below is the short version.

If you would rather see all of that run before deploying any of it, the full scenario matrix lives in microvm-handoff-demo : nine scenarios on Step Functions and on a durable function plus one lease from the CLI, with every execution history, VM log, and orchestrator log checked in, the benchmarks rerun on 0.3.1 (a single lease at a p50 of 4.3 s on both orchestrators, a fan-out of four at 4.6 s on Step Functions and 7.9 s on the durable function, a fan-out of eight at 8.9 s and 13.7 s), and a console screenshot of each execution. Its first pass on 0.3.0 is where the two fixes in 0.3.1 came from.
